HDI PCB

High Density Interconnect PCB for advanced electronics

HDI (High Density Interconnect) PCBs are printed circuit boards with a higher wiring density per unit area than conventional PCBs. HDI PCBs have finer lines and spaces, smaller vias and capture pads, and higher connection pad density.

Jichangsheng Technology provides 4-20 layer HDI PCBs with laser drill holes down to 0.075mm (3mil). We support 1+N+1, 2+N+2, and any-layer HDI constructions.

HDI technology enables smaller, lighter, and more reliable products. It is widely used in smartphones, tablets, medical devices, and other high-performance electronics.

Key Features

4-20 layer HDI
Laser drill down to 0.075mm (3mil)
Trace/space down to 2.4/2.4mil
Blind and buried vias
Via-in-pad (filled vias)
1+N+1, 2+N+2 construction
Any-layer HDI available
ENIG surface finish

Applications

SmartphonesTabletsMedical DevicesAerospaceAutomotiveIoT Devices

Jichangsheng Technology is a leading PCB manufacturer in Shenzhen, China. We provide high-quality HDI PCB with competitive pricing, quick turnaround, and excellent customer service. ISO 9001:2015 certified, RoHS compliant.
